| Varenummer | TMS156WX1-02TC |
| Mærke | Tianma |
| Størrelse | 15.6 |
| Ansøgning | DMPC |
| Løsning | 1366×768 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | AVIC |
| panel model | TMS156WX1-02TC |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 15.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 344.232×193.536 mm |
| overflade | |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 2/6 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
