| Varenummer | BP096WX1-100 |
| Mærke | BOE |
| Størrelse | 9.6 |
| Ansøgning | PAD |
| Løsning | 800×1280 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BP096WX1-100 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.6 inch |
| løsning | 800(RGB)×1280 , WXGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 129×206.4 mm |
| omrids | 136.8×217.1×4.2 mm |
| overflade | Antiglare (Haze 3.1%) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S4PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 45 pins |
| indgangsspænding | 1.8/3.7V (Typ.)(VDD/VDDI) |
| Ansøgning | PAD |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HJ080IA-01B | Innolux | 8.0 | 1024×768 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| LD083WU1-SPA3 | LG Display | 8.3 | 1200×1920 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
