| Varenummer | BRS-320H02 |
| Mærke | |
| Størrelse | 32.0 |
| Ansøgning | IA |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 2000 |
| CR | 5000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | BERISE |
| panel model | BRS-320H02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 32.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | SVA, Normally Black, Transmissive |
| aktivt område | 698.4×392.85 mm |
| omrids | 737.6×433 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 2000 cd/m² (Typ.) |
| kontrastforhold | 5000:1 (Typ.) |
| vise farver | 1.07B (8-bit + Dithering), CIE193171% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
