| Varenummer | LM340UW1-SSA1 |
| Mærke | LG Display |
| Størrelse | 34 |
| Ansøgning | IA |
| Løsning | 3440×1440 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 1000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LM340UW1-SSA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 34 inch |
| løsning | 3440(RGB)×1440 |
| visningstilstand | AH-IPS, Normally Black, Transmissive |
| aktivt område | 799.8×334.8 mm |
| omrids | 820.8×361×19.8 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 1.07B (8-bit + Hi-FRC), sRGB100% |
| responstid | 14 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 12S4PWLEDWithout Driver |
| signal interface | LVDS (8 ch, 10-bit), 174 pins |
| indgangsspænding | 10.0V (Typ.) |
| Ansøgning | IA |
