| Varenummer | CLAA070LD0DCW |
| Mærke | CPT |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 450:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | CPT |
| panel model | CLAA070LD0DCW |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 163.8×103.9×6.35 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S7PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit), 60 pins |
| indgangsspænding | 3.3/9.6/18/-6V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | CNS |
| CLAA070LB01CW | CPT | 7.0 | 800×480 |
| CLAA070LC0DCW | CPT | 7.0 | 800×480 |
| CLAA070LFA1 CW | CPT | 7.0 | 800×480 |
| CLAA070LFB1 CW | CPT | 7.0 | 800×480 |
| CLAA070MA32BW | CPT | 7.0 | 800×600 |
| CLAA070NB02CT | CPT | 7.0 | 1024×600 |
| CLAA070NC0DCT | CPT | 7.0 | 1024×600 |
| CLAA070ND22CW | CPT | 7.0 | 1024×600 |
| CLAA070ND30CW | CPT | 7.0 | 1024×600 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| C065GW04 V2 | AUO | 6.5 | 400×240 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LQ050Q5DR01 | SHARP | 5.0 | 320×240 |
| LQ080T5GG01B | SHARP | 8.0 | 480×234 |
| LQ080Y5CGQ2 | SHARP | 8.0 | 800×480 |
| LQ6BW51N | SHARP | 5.8 | 480×234 |
| ND078-101A1 | SEBO | 7.8 | 1280×400 |
| PD050VX6 | E Ink | 5.0 | 640×480 |
| TX18D35VM0AAA | KOE | 7.0 | 800×480 |
