| Varenummer | CLAA102NA2CCN |
| Mærke | CPT |
| Størrelse | 10.2 |
| Ansøgning | PDVD |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA102NA2CCN |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.2 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 222.72×130.5 mm |
| omrids | 235.2×145.8×6 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/25/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
