| Varenummer | A070VW01 V2 |
| Mærke | AUO |
| Størrelse | 7.0 |
| Ansøgning | PDVD |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 330 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A070VW01 V2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 152.4×91.44 mm |
| overflade | Antiglare (Haze 5.5%) |
| lysstyrke | 330 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 12/18 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLED |
| signal interface | TTL (1 ch, 6-bit) |
| Ansøgning | PDVD |
