| Varenummer | DLC0160AUG |
| Mærke | Other |
| Størrelse | 1.6 |
| Ansøgning | SW |
| Løsning | 240×240 |
| Sammensætning | LCM |
| Lysstyrke | 210 |
| CR | 130:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | DLC |
| panel model | DLC0160AUG 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 1.6 inch |
| løsning | 240(RGB)×240 |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 28.8×28.8 mm |
| omrids | 31.2×35.1×1.65 mm |
| overflade | |
| lysstyrke | 210 cd/m² (Typ.) |
| kontrastforhold | 130:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit), CIE193140% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S1PWLEDWithout Driver |
| signal interface | 8/9-bit 8080 parallel, 24 pins |
| indgangsspænding | 2.8/(1.8/2.8) (Typ.)(VCI/IOVCC) |
| Ansøgning | SW |
| DLC0104AZOG | Other | 1.0 | 128×32 |
| DLC0154AZG-T | Other | 1.54 | 240×240 |
| DLC0160AUG | Other | 1.6 | 240×240 |
| OEL9M0053-Y-E | Other | 1.6 | 128×64 |
| RGS16128064YR000 | RiTdisplay | 1.6 | 128×64 |
| LPM010R030B | JDI | 0.99 | 180×180 |
| OEL9M0082-R-E | Other | 1.1 | 128×128 |
| OEL9M0084-G-E | Other | 0.91 | 128×32 |
| OEL9M0084-R-E | Other | 0.91 | 128×32 |
| OEL9M1004-L4-E | Other | 1.5 | 128×128 |
| OEL9M1010-R-E | Other | 0.95 | 96×64 |
| RGS13128096BH000 | RiTdisplay | 1.3 | 128×96 |
| RGS13128096WH000 | RiTdisplay | 1.3 | 128×96 |
| RGS18160128FH007 | RiTdisplay | 1.8 | 160×128 |
| UG-S009TSWAGF3 | WiseChip | 1.1 | 160×128 |
