| Varenummer | EV121X0M-N10 |
| Mærke | BOE |
| Størrelse | 12.1 |
| Ansøgning | Industrial |
| Løsning | 1024×768 |
| Sammensætning | a-Si TFT-LCD , LCM |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | BOE |
| diagonal størrelse | 12.1 inch |
| pixel format | 1024(RGB)×768 [XGA] 105PPI |
| aktivt område | 245.76(H)×184.32(V) mm |
| bezel område | 249(H)×187.5(V) mm |
| luminans | 500 cd/m² (Typ.) |
| visningsretning | Symmetry |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10) |
| støtte farve | 16.7M 72% NTSC |
| vægt | 520g (Max.) |
| billedhastighed | 60Hz |
| interface type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | EV121X0M-N10 |
| type | a-Si TFT-LCD , LCM |
| konfiguration | RGB Vertical Stripe |
| omrids dim. | 260.5(H)×204(V) ×9.2(D) mm |
| behandling | - |
| kontrastforhold | 1200:1 (Typ.) (TM) |
| responstid | 25 (Typ.)(Tr+Td) |
| driftstilstand | ADS, Normally Black, Transmissive |
| lyskilde | WLED , 50K hours , With LED Driver |
| designet til | Industrial |
| berøringspanel | Without |
| AA121SJ03 | Mitsubishi | 12.1 | 800×600 |
| AA121SP01 | Mitsubishi | 12.1 | 800×600 |
| LQ121S1DC71 | SHARP | 12.1 | 800×600 |
| LQ121S1LG81 | SHARP | 12.1 | 800×600 |
| LT121EE16000 | TOSHIBA | 12.1 | 1280×800 |
| LTD121EDDZ | TOSHIBA | 12.1 | 1024×768 |
| LTD121EWRF | TOSHIBA | 12.1 | 1280×800 |
| LTD121KC6K | TOSHIBA | 12.1 | 1024×768 |
| LTN121AT08 | Samsung | 12.1 | 1280×800 |
| LTN121XJ-L07 | Samsung | 12.1 | 1024×768 |
