| Varenummer | G121AGE-L03 |
| Mærke | Innolux |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1500:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | G121AGE-L03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | Super MVA, Normally Black, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 260.5×204×8.9 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1500:1 (Typ.) |
| vise farver | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| responstid | 13/12 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VCC) |
| Ansøgning | IA |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| AA121SP01 | Mitsubishi | 12.1 | 800×600 |
| B121EW13 V1 | AUO | 12.1 | 1280×800 |
| G121AGE-L03 | Innolux | 12.1 | 800×600 |
| G121S1-L02 | Innolux | 12.1 | 800×600 |
| LTD121EWEK | TOSHIBA | 12.1 | 1280×800 |
| LTD121KC6K | TOSHIBA | 12.1 | 1024×768 |
| LTN121AT01-002 | Samsung | 12.1 | 1280×800 |
| M121MNS1 R1 | IVO | 12.1 | 800×600 |
| NL8060BC31-47 | NLT | 12.1 | 800×600 |
| G043FW01 V0 | AUO | 4.3 | 480×272 |
| G057VN01 V0 | AUO | 5.7 | 640×480 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| G150XTT01.0 | AUO | 15.0 | 1024×768 |
| LM64C12P | SHARP | 9.4 | 640×480 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| M104GNX1 R1 | IVO | 10.4 | 1024×768 |
| NL6448BC33-64E | NLT | 10.4 | 640×480 |
| TX20D28VM2BAB | KOE | 8.0 | 800×480 |
| UMSH-8065MD-11T | Other | 3.5 | 320×240 |
