| Varenummer | G121EAN01.4 |
| Mærke | AUO |
| Størrelse | 12.1 |
| Ansøgning | Industrial Medical I |
| Løsning | 1280×800 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| fabrikant | AUO |
| skærmstørrelse | 12.1 inch |
| pixel antal | 1280(RGB)×800 (WXGA) 124PPI |
| aktivt område (mm) | 261.12 × 163.2 (H×V) |
| rammeareal (mm) | 264.22 × 168.12 (H×V) |
| luminans | 300 cd/m² (Typ.) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| god udsigt kl | Symmetry |
| farvedybde | 262K/16.2M 99% sRGB |
| masse | 480g (Max.) |
| opdateringshastighed | 60Hz |
| signaltype | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
| modelnavn | G121EAN01.4 |
| skærmtype | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| omrids (mm) | 278 × 184 × 9.64 (H×V×D) |
| behandling | Antiglare, Hard coating (3H) |
| kontrastforhold | 1000 : 1 (Typ.) (TM) |
| respons | 25 (Typ.)(Tr+Td) ms |
| arbejdstilstand | AHVA, Normally Black, Transmissive |
| baggrundsbelysning | WLED , 30K hours , With LED Driver |
| anvendes til | Industrial Medical Imaging |
| berøringsskærm | Without |
| AA121SN03 | Mitsubishi | 12.1 | 800×600 |
| AC121SA01 | Mitsubishi | 12.1 | 800×600 |
| B121EW03 V9 | AUO | 12.1 | 1280×800 |
| DLC1210BBG | Other | 12.1 | 800×600 |
| LQ121S1DG41 | SHARP | 12.1 | 800×600 |
| LQ121S1LG72 | SHARP | 12.1 | 800×600 |
| LT121SU-125 | Samsung | 12.1 | 800×600 |
| LTD121EDDZ | TOSHIBA | 12.1 | 1024×768 |
| LTD121EWUD | TOSHIBA | 12.1 | 1280×800 |
| TM121SV-02L11 | SANYO | 12.1 | 800×600 |
