| Varenummer | G156HAN02.1 |
| Mærke | AUO |
| Størrelse | 15.6 |
| Ansøgning | Industrial Medical I |
| Løsning | 1920×1080 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| fabrikant | AUO |
| skærmstørrelse | 15.6 inch |
| pixel antal | 1920(RGB)×1080 (FHD) 141PPI |
| aktivt område (mm) | 344.16 × 193.59 (H×V) |
| rammeareal (mm) | 347.06 × 196.49 (H×V) |
| luminans | 500 cd/m² (Typ.) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| god udsigt kl | Symmetry |
| farvedybde | 16.7M 99% sRGB |
| masse | 600/660g (Typ./Max.) |
| opdateringshastighed | 60Hz |
| signaltype | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
| modelnavn | G156HAN02.1 |
| skærmtype | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| omrids (mm) | 363.8 × 215.9 × 9.3 (H×V×D) |
| behandling | Antiglare, Hard coating (3H) |
| kontrastforhold | 1000 : 1 (Typ.) (TM) |
| respons | 25 (Typ.)(Tr+Td) ms |
| arbejdstilstand | AHVA, Normally Black, Transmissive |
| baggrundsbelysning | WLED , 50K hours , With LED Driver |
| anvendes til | Industrial Medical Imaging |
| berøringsskærm | Without |
