| Varenummer | G170ETN03.1 |
| Mærke | AUO |
| Størrelse | 17.0 |
| Ansøgning | Industrial |
| Løsning | 1280×1024 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | AUO |
| model | G170ETN03.1 |
| diagonal størrelse | 17.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×1024 [SXGA] 96PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 337.92(H)×270.336(V) mm |
| omrids dim. | 358.5(H)×296.5(V) ×10.8(D) mm |
| bezel område | 341.7(H)×274.1(V) mm |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | - |
| responstid | 3.8/1.2 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10) |
| driftstilstand | TN, Normally White, Transmissive |
| støtte farve | 16.7M 72% NTSC |
| lyskilde | WLED [9S4P] , 30K hours , W/O Driver |
| vægt | 1.27Kgs (Typ.) |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Strømforsyning | 5.0V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
