| Varenummer | H139BLN01.2 |
| Mærke | AUO |
| Størrelse | 1.39 |
| Ansøgning | SW |
| Løsning | 400×400 |
| Sammensætning | OLED |
| Lysstyrke | 300 |
| CR | 10000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | H139BLN01.2 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 1.39 inch |
| løsning | 400(RGB)×400 |
| aktivt område | 35.4×35.4 mm |
| omrids | 38.6×40.5×0.79 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Min.) |
| vise farver | 16.7M (8-bit), CIE1931103% |
| synsvinkel | 80/80/80/80 (Min.)(CR≥1600)(L/R/U/D) |
| driver ic | COF Built-in RM69080 |
| signal interface | MIPI (1 data lane), 20 pins |
| indgangsspænding | 1.8/2.8/4.6/-2.4V (Typ.)(VDDIO/VCI/ELVDD/ELVSS) |
| Ansøgning | SW |
