| Varenummer | HSD150PX16-A |
| Mærke | HannStar |
| Størrelse | 15.0 |
| Ansøgning | NBPC |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 250:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | HannStar |
| panel model | HSD150PX16-A |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| omrids | 317.3×242 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFL |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| rohs: | |
| Ansøgning | NBPC |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| HSD150PX14-A00 | HannStar | 15.0 | 1024×768 |
| HSD150PX16-A | HannStar | 15.0 | 1024×768 |
| LQ150X1DG11 | SHARP | 15.0 | 1024×768 |
| LQ150X1LX95 | SHARP | 15.0 | 1024×768 |
| LTA150B850F | TOSHIBA | 15.0 | 1024×768 |
| LTN150PG-L03 | Samsung | 15.0 | 1400×1050 |
| N150P5-L02 | Innolux | 15.0 | 1400×1050 |
| N150X3-L09 | Innolux | 15.0 | 1024×768 |
| TX38D12VC0CAA | KOE | 15.0 | 1024×768 |
| HB140WH1-504 | BOE | 14.0 | 1366×768 |
| LP141WP2-TLA2 | LG Display | 14.1 | 1440×900 |
| LP141WX3-TLA4 | LG Display | 14.1 | 1280×800 |
| LP154WP4-TLB1 | LG Display | 15.4 | 1440×900 |
| LQ133T1JW19 | SHARP | 13.3 | 2560×1440 |
| LT121DEE3P00 | TOSHIBA | 12.1 | 1024×768 |
| LTM15C460F | TOSHIBA | 15.0 | 1024×768 |
| LTN140KT13-B01 | Samsung | 14.0 | 1600×900 |
| LTN156AT02-D03 | Samsung | 15.6 | 1366×768 |
| N133BGE-E31 | Innolux | 13.3 | 1366×768 |
