| Varenummer | LQ133T1JW19 |
| Mærke | SHARP |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 2560×1440 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | SHARP |
| panel model | LQ133T1JW19 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 2560(RGB)×1440 , Quad-HD |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 293.76×165.24 mm |
| omrids | 304.98×178.2×2.6 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare (Haze 42%) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (4 Lanes), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B133XW03 V0 | AUO | 13.3 | 1366×768 |
| LP133WH2-TLL4 | LG Display | 13.3 | 1366×768 |
| LQ133K1LA04 | SHARP | 13.3 | 1280×800 |
| LQ133K1LA4A | SHARP | 13.3 | 1280×800 |
| LQ133K1LD4B | SHARP | 13.3 | 1280×800 |
| LQ133M1JW03 | SHARP | 13.3 | 1920×1080 |
| LQ133T1JW01 | SHARP | 13.3 | 2560×1440 |
| LQ133T1JW02 | SHARP | 13.3 | 2560×1440 |
| LQ133T1JW19 | SHARP | 13.3 | 2560×1440 |
| N133FGE-L31 | Innolux | 13.3 | 1600×900 |
| B140HTN01.3 | AUO | 14.0 | 1920×1080 |
| B156HTN03.3 | AUO | 15.6 | 1920×1080 |
| B156HW03 V0 | AUO | 15.6 | 1920×1080 |
| LP121X04-A2 | LG Display | 12.1 | 1024×768 |
| LP133WH2-SPA2 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLM2 | LG Display | 13.3 | 1366×768 |
| LP141X2 | LG Display | 14.1 | 1024×768 |
| LP156WF6-SPH3 | LG Display | 15.6 | 1920×1080 |
| LTN154AT13-701 | Samsung | 15.4 | 1280×800 |
| N156B6-L06 | Innolux | 15.6 | 1366×768 |
