| Varenummer | HT185WX1-100 |
| Mærke | BOE |
| Størrelse | 18.5 |
| Ansøgning | DMPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | BOE |
| panel model | HT185WX1-100 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 409.8×230.4 mm |
| omrids | 430.4×254.6×16.5 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 1.5/3.5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| HT185WX1-100 | BOE | 18.5 | 1366×768 |
| HT185WX1-300 | BOE | 18.5 | 1366×768 |
| LM185WH1-TLH1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| M185BGE-L23 | Innolux | 18.5 | 1366×768 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M185XTN01.3 | AUO | 18.5 | 1366×768 |
| M185XW01 V2 | AUO | 18.5 | 1366×768 |
| M185XW01 V5 | AUO | 18.5 | 1366×768 |
| M185XW01 V6 | AUO | 18.5 | 1366×768 |
| CLAA170ES01E | CPT | 17.0 | 1280×1024 |
| HSD190MEN3-A00 | HannStar | 19.0 | 1280×1024 |
| HT236F01-100 | BOE | 23.6 | 1920×1080 |
| LM170E01-TLA1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLL2 | LG Display | 17.0 | 1280×1024 |
| LM185TT1A | PANDA | 18.5 | 1366×768 |
| LM300W01-STA4 | LG Display | 30.0 | 2560×1600 |
| M150EW01 V0 | AUO | 15.0 | 1280×720 |
| M170EG01 VG | AUO | 17.0 | 1280×1024 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
