| Varenummer | M150EW01 V0 |
| Mærke | AUO |
| Størrelse | 15.0 |
| Ansøgning | DMPC |
| Løsning | 1280×720 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | M150EW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1280(RGB)×720 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 332.16×186.84 mm |
| omrids | 354.1×227.4 mm |
| overflade | Antiglare |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193145% |
| responstid | 5/3 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | DMPC |
