| Varenummer | HV208QX1-100 |
| Mærke | HYDIS |
| Størrelse | 20.8 |
| Ansøgning | MD |
| Løsning | 2048×1536 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 700:1 |
| Farver | Grayscale |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | BOE HYDIS |
| panel model | HV208QX1-100 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.8 inch |
| løsning | 2048(LCR)×1536 , QXGA |
| visningstilstand | AFFS, Normally Black, Transmissive |
| aktivt område | 423.9×318 mm |
| omrids | 457×350 mm |
| overflade | Antiglare (Haze 13%), Hard coating (3H) |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | Grayscale (8-bit) |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 12 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (4 ch, 8-bit), 70 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
| IAUX61 | IDTech | 19.6 | 1600×1200 |
| ITQX21G | IDTech | 20.8 | 2048×1536 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| R208RFE-L05 | Innolux | 20.8 | 2048×1536 |
| R213T3-L01 | Innolux | 21.3 | 2560×2048 |
| R300M1-L01 | Innolux | 30.0 | 4096×2560 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
| VVX28T143H00 | Panasonic | 28.0 |
