| Varenummer | R300M1-L01 |
| Mærke | Innolux |
| Størrelse | 30.0 |
| Ansøgning | MD |
| Løsning | 4096×2560 |
| Sammensætning | LCM |
| Lysstyrke | 1200 |
| CR | 800:1 |
| Farver | Grayscale |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | R300M1-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 30.0 inch |
| løsning | 4096(LCR)×2560 , DQSXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 645.12×403.2 mm |
| omrids | 678×448×49.5 mm |
| overflade | Antiglare (Haze 40%), Hard coating (3H) |
| lysstyrke | 1200 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Min.) |
| vise farver | Grayscale (10-bit) |
| responstid | 50/15 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 50Hz |
| lampe type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (4 ch, 10-bit), 82 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
