| Varenummer | KCS057QV1BH-G20 |
| Mærke | Kyocera |
| Størrelse | 5.7 |
| Ansøgning | Industrial |
| Løsning | 320×240 |
| Sammensætning | LCM, CSTN-LCD |
| Lysstyrke | |
| CR | 40:1 |
| Farver | Color |
| Baggrundsbelysning | 1 |
| Interface | Parallel |
| fabrikant | Kyocera |
| modelnavn | KCS057QV1BH-G20 |
| skærmstørrelse | 5.7 inch |
| skærmtype | LCM, CSTN-LCD |
| pixel antal | 320(RGB)×240 (QVGA) 70PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 115.2 × 86.4 (H×V) |
| omrids (mm) | - |
| luminans | - |
| kontrastforhold | 40 : 1 (Typ.) (TM) |
| synsvinkel | 50/50/30/30 (Typ.)(CR≥2) |
| respons | 220/110 (Typ.)(Tr/Td) ms |
| god udsigt kl | - |
| arbejdstilstand | STN, Normally Black, Transmissive |
| farvedybde | Color |
| baggrundsbelysning | 1 pcs CCFL , 40K hours , No Driver |
| masse | - |
| anvendes til | Industrial |
| opdateringshastighed | - |
| berøringsskærm | Without |
| signaltype | Parallel Data (1ch, 8-bit) , Connector 15 pins |
