| Varenummer | KG057QV1CA-G020 |
| Mærke | Kyocera |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 260 |
| CR | 4:1 |
| Farver | Monochrome |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | Kyocera |
| panel model | KG057QV1CA-G020 |
| paneltype | STN-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 320×240 , QVGA |
| visningstilstand | STN, Blue mode (Negative), Transmissive |
| aktivt område | 115.18×86.38 mm |
| omrids | 144×104.8×13.2 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 260 cd/m² (Typ.) |
| kontrastforhold | 4:1 (Typ.) |
| vise farver | Monochrome |
| responstid | 380/120 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekvens | 75Hz |
| lampe type | 1 pcsCCFLOptional |
| signal interface | Parallel Data (4-bit), 20 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VDD) |
| Ansøgning | IA |
