| Varenummer | LC185EXN-SCA1 |
| Mærke | LG Display |
| Størrelse | 18.5 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LC185EXN-SCA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 409.8×230.4 mm |
| omrids | 430.4×254.6×14.9 mm |
| overflade | Antiglare (Haze 13%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Dithering), CIE193168% |
| responstid | 9 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | LCTV |
| CLAA185WA02 | CPT | 18.5 | 1366×768 |
| CLAA185WA04 | CPT | 18.5 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LC185EXN-SCA1 | LG Display | 18.5 | 1366×768 |
| LC185EXN-SDA1 | LG Display | 18.5 | 1366×768 |
| LC185WH1-TLG1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| M185B3-LA1 | Innolux | 18.5 | 1366×768 |
| M185BGE-L2U | Innolux | 18.5 | 1366×768 |
| LC320EUD-SEF1 | LG Display | 31.5 | 1920×1080 |
| LC320WUN-SCB1 | LG Display | 31.5 | 1920×1080 |
| LC370WUD-SCB1 | LG Display | 37 | 1920×1080 |
| LC420DUE-SFR1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SBC1 | LG Display | 42 | 1920×1080 |
| LTA400HM21 | Samsung | 40 | 1920×1080 |
| LTF550HF04-A05 | Samsung | 55 | 1920×1080 |
| T260XW03 V0 | AUO | 26.0 | 1366×768 |
| V460H1-LS1 | Innolux | 46 | 1920×1080 |
| V580HK1-LE6 | Innolux | 58 | 1920×1080 |
