| Varenummer | LC470WUN-SDA1 |
| Mærke | LG Display |
| Størrelse | 47 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 1450:1 |
| Farver | 16.7M/1.06B |
| Baggrundsbelysning | |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LC470WUN-SDA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 47 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 1039.68×584.82 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 1450:1 (Typ.) |
| vise farver | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
| responstid | 5 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | Embedded (Inverter) |
| signal interface | LVDS |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LC470WU1-SLA1 | LG Display | 47 | 1920×1080 |
| LC470WUD-SCM1 | LG Display | 47 | 1920×1080 |
| LC470WUE-SDP1 | LG Display | 47 | 1920×1080 |
| LC470WUE-SEP1 | LG Display | 47 | 1920×1080 |
| LC470WUF-SBF1 | LG Display | 47 | 1920×1080 |
| LC470WUF-SCA2 | LG Display | 47 | 1920×1080 |
| LC470WUF-SCA3 | LG Display | 47 | 1920×1080 |
| LC470WUL-SBT1 | LG Display | 47 | 1920×1080 |
| LC470WUN-SCA1 | LG Display | 47 | 1920×1080 |
| LC470WUN-SDA1 | LG Display | 47 | 1920×1080 |
| LC320DXE-FGA3 | LG Display | 31.5 | 1366×768 |
| LC370WUN-SCC1 | LG Display | 37 | 1920×1080 |
| LC650DUF-FGA2 | LG Display | 65 | 1920×1080 |
| LSC460HN03-W | Samsung | 46 | 1920×1080 |
| LTA230AP01 | Samsung | 23.0 | 1366×768 |
| LTA260AP01 | Samsung | 26.0 | 1366×768 |
| T315XW02 VV | AUO | 31.5 | 1366×768 |
| V260B2-L01 | Innolux | 26.0 | 1366×768 |
| V390HK1-LS6 | Innolux | 39 | 1920×1080 |
| V400DK2-KS5 | Innolux | 40 | 3840×2160 |
