| Varenummer | LD470DUE-SFR1 |
| Mærke | LG Display |
| Størrelse | 47 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LD470DUE-SFR1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 47 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 1039.68×584.82 mm |
| omrids | 1067.6×617.4 mm |
| overflade | Antiglare (Haze 1%), Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193168% |
| responstid | |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| LD420WUB-SBA1 | LG Display | 42 | 1920×1080 |
| LD420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LD470WUB-SCA1 | LG Display | 47 | 1920×1080 |
| LD550WUP-SCA1 | LG Display | 55 | 1920×1080 |
| LK695D3LA18 | SHARP | 70 | 1920×1080 |
| LTI460AA01-001 | Samsung | 46 | 1366×768 |
| LTI550HN03 | Samsung | 55 | 1920×1080 |
| ND168TXP01 | 16.8 | 1366×378 | |
| P380HVN01.0 | AUO | 38 | 1920×502 |
| P650HVN02.6 | AUO | 65 | 1920×1080 |
