| Varenummer | ND168TXP01 |
| Mærke | |
| Størrelse | 16.8 |
| Ansøgning | PID |
| Løsning | 1366×378 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | |
| panel model | ND168TXP01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 16.8 inch(1/2 cut of 18.5") |
| løsning | 1366(RGB)×378 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 409.8×113.4 mm |
| omrids | 430.37×137.3×11.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193171% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | PID |
