| Varenummer | LM-GK53-22NTX |
| Mærke | SANYO |
| Størrelse | 13.6 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 150 |
| CR | 20:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | TORISAN |
| panel model | LM-GK53-22NTX |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 13.6 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 276.48×207.36 mm |
| omrids | 336×249.4 mm |
| overflade | |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 20:1 (Typ.) |
| vise farver | Color |
| responstid | 150/100 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/25/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz |
| lampe type | CCFLWithout Driver |
| signal interface | Parallel Data (2ch, 12-bit), 40 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
