| Varenummer | NL4823BC37-05 |
| Mærke | NLT |
| Størrelse | 7.0 |
| Ansøgning | IA |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | NEC |
| panel model | NL4823BC37-05 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 154.08×87.05 mm |
| omrids | 174.5×105.5×11 mm |
| overflade | Clear, Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193140% |
| responstid | 6/19 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 31 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | IA |
| A070VW08 V0 | AUO | 7.0 | 800×480 |
| CLAA070LC0CCW | CPT | 7.0 | 800×480 |
| CLAA070NB02CT | CPT | 7.0 | 1024×600 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| LA070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LQ070T5DG01 | SHARP | 7.0 | 854×480 |
| LQ070T5GC01 | SHARP | 7.0 | |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| NL4823BC37-05 | NLT | 7.0 | 480×234 |
| AA057QD01 | Mitsubishi | 5.7 | 320×240 |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| AA121XJ02 | Mitsubishi | 12.1 | 1024×768 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| LM641836R | SHARP | 9.4 | 640×480 |
| LQ10D32M | SHARP | 10.4 | 640×480 |
| LTM09C015A | TOSHIBA | 9.4 | 640×480 |
| NL6448BC20-08E | NLT | 6.5 | 640×480 |
| OEL9M0078-W-E | Other | 1.45 | 132×16 |
| SH320240C | Other | 5.7 | 320×240 |
