| Varenummer | LM081HB1T01 |
| Mærke | SHARP |
| Størrelse | 8.1 |
| Ansøgning | IA |
| Løsning | 640×240 |
| Sammensætning | LCM |
| Lysstyrke | 150 |
| CR | 8:1 |
| Farver | Monochrome |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | SHARP |
| panel model | LM081HB1T01 |
| paneltype | FSTN-LCD , LCM |
| panelstørrelse | 8.1 inch |
| løsning | 640×240 , HVGA |
| visningstilstand | STN, Black/White (Negative) |
| aktivt område | 191.99×71.99 mm |
| omrids | 249×99.4 mm |
| overflade | |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 8 : 1 (Typ.) |
| vise farver | Monochrome |
| responstid | 430/170 (Typ.)(Tr/Td) |
| synsvinkel | 30/30/20/35 (Typ.)(CR≥2)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (4-bit), 15 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
