| Varenummer | LM12S029 |
| Mærke | SHARP |
| Størrelse | 12.1 |
| Ansøgning | NBPC |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 80 |
| CR | 40:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LM12S029 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 275×202.5 mm |
| overflade | |
| lysstyrke | 80 cd/m² (Typ.) |
| kontrastforhold | 40:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 150 (Typ.)(Tr+Td) |
| synsvinkel | |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | NBPC |
