| Varenummer | LM12S49 |
| Mærke | SHARP |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 185 |
| CR | 40:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LM12S49 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 275×202.5×8.5 mm |
| overflade | |
| lysstyrke | 185 cd/m² (Typ.) |
| kontrastforhold | 40:1 (Typ.) |
| vise farver | Color |
| responstid | 220/80 (Typ.)(Tr/Td) |
| synsvinkel | 30/30/15/25 (Typ.)(CR≥5)(L/R/U/D) |
| frekvens | 120Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | CMOS/TTL (1 ch, 8-bit), 41 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VDD) |
| Ansøgning | IA |
