| Varenummer | UG-6028GDEBF02 |
| Mærke | WiseChip |
| Størrelse | 1.7 |
| Ansøgning | IA |
| Løsning | 160×128 |
| Sammensætning | OLED |
| Lysstyrke | 75 |
| CR | 2000:1 |
| Farver | 262K |
| Baggrundsbelysning | self |
| Interface | CPU/RGB/SPI |
| panel mærke | WiseChip |
| panel model | UG-6028GDEBF02 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 1.7 inch |
| løsning | 160(RGB)×128 |
| aktivt område | 33.575×26.864 mm |
| omrids | 39.9×34×1.7 mm |
| overflade | |
| lysstyrke | 75 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Typ.) |
| vise farver | 262K (6-bit) |
| synsvinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| driver ic | COF Built-in SEPS525 |
| signal interface | 8/9-bit 8080 parallel, 6-bit RGB, 4-wire SPI, 35 pins |
| indgangsspænding | 2.8/2.8/14.0V (VDD/VDDIO/VDDH) |
| rohs: | |
| Ansøgning | IA |
