| Varenummer | LM150X07-B4 |
| Mærke | LG Display |
| Størrelse | 15.0 |
| Ansøgning | DMPC |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 350:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LM150X07-B4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| omrids | 331.3×257.9×11.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 7/18 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | DMPC |
| DLC1500AMG-1 | Other | 15.0 | 1024×768 |
| LM150X06-A3M2 | LG Display | 15.0 | 1024×768 |
| LM150X06-A4C4 | LG Display | 15.0 | 1024×768 |
| LM150X07-B4 | LG Display | 15.0 | 1024×768 |
| LM150X08-A4K3 | LG Display | 15.0 | 1024×768 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM150X08-TL01 | LG Display | 15.0 | 1024×768 |
| LM150X08-TLB1 | LG Display | 15.0 | 1024×768 |
| LQ150X1LG92 | SHARP | 15.0 | 1024×768 |
| LTM150XH-L04 | Samsung | 15.0 | 1024×768 |
| CLAA150XM05 | CPT | 15.0 | 1024×768 |
| CLAA170EA10 | CPT | 17.0 | 1280×1024 |
| FLC38XGC6V-06 | Fujitsu | 15.0 | 1024×768 |
| LM190E05-SL03 | LG Display | 19.0 | 1280×1024 |
| LM230WF5-TLA3 | LG Display | 23.0 | 1920×1080 |
| M200RW01 V6 | AUO | 20.0 | 1600×900 |
| M215H1-L03 | Innolux | 21.5 | 1920×1080 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| NA19020-C262 | Fujitsu | 15.0 | 1024×768 |
| P190MWW1-404 | IVO | 19.0 | 1440×900 |
