| Varenummer | P190MWW1-404 |
| Mærke | IVO |
| Størrelse | 19.0 |
| Ansøgning | DMPC |
| Løsning | 1440×900 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | IVO |
| panel model | P190MWW1-404 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 19.0 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 410.4×256.5 mm |
| omrids | 420.04×266.18 mm |
| overflade | Antiglare, Hard coating |
| glas dybde | 0.70+0.70 mm |
| transmissivitet | 5.23% (Typ.)(with Polarizer) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| AA190EA01 | Mitsubishi | 19.0 | 1280×1024 |
| G190ETN01.4 | AUO | 19.0 | 1280×1024 |
| LM190E05-SL02 | LG Display | 19.0 | 1280×1024 |
| LM190E08-TLG3 | LG Display | 19.0 | 1280×1024 |
| LTM190EX-L05 | Samsung | 19.0 | 1280×1024 |
| M190EN04 V5 | AUO | 19.0 | 1280×1024 |
| MV190E0M-N10 | BOE | 19.0 | 1280×1024 |
| NL128102BC29-01 | NLT | 19.0 | 1280×1024 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
| P190MWW1-404 | IVO | 19.0 | 1440×900 |
| CLAA260WU09 | CPT | 25.5 | 1920×1200 |
| HM215WU3-100 | BOE | 21.5 | 1920×1080 |
| LM170E01-A4 | LG Display | 17.0 | 1280×1024 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LTM270TT01 | Samsung | 27.0 | 2048×1152 |
| M170EG01 VA | AUO | 17.0 | 1280×1024 |
| M170EN04 V6 | AUO | 17.0 | 1280×1024 |
| M185XW01 V1 | AUO | 18.5 | 1366×768 |
| M190A1-L0A | Innolux | 19.0 | 1440×900 |
| M220Z1-L0A | Innolux | 22.0 | 1680×1050 |
