| Varenummer | LM64183P |
| Mærke | SHARP |
| Størrelse | 9.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 70 |
| CR | 11:1 |
| Farver | Monochrome |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | SHARP |
| panel model | LM64183P |
| paneltype | FSTN-LCD , LCM |
| panelstørrelse | 9.4 inch |
| løsning | 640×480 , VGA |
| visningstilstand | STN, Black/White (Negative), Transmissive |
| aktivt område | 191.97×143.97 mm |
| omrids | 260×174 mm |
| overflade | |
| lysstyrke | 70 cd/m² (Typ.) |
| kontrastforhold | 11:1 (Typ.) |
| vise farver | Monochrome |
| responstid | 350/200 (Typ.)(Tr+/Td) |
| synsvinkel | 20/25/25/15 (Typ.)(CR>4)(L/R/U/D) |
| frekvens | 85Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (4-bit), 15 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
