| Varenummer | LP140WH8-TPH1 |
| Mærke | LG Display |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LP140WH8-TPH1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 309.4×173.95 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | eDP (2 Lanes) |
| Ansøgning | NBPC |
| LP140WF1-SPU1 | LG Display | 14.0 | 1920×1080 |
| LP140WF5-SPB2 | LG Display | 14.0 | 1920×1080 |
| LP140WH2-TLB1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLF1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLC1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLN1 | LG Display | 14.0 | 1366×768 |
| LP140WH8-TPH1 | LG Display | 14.0 | 1366×768 |
| LP140WHU-TPB2 | LG Display | 14.0 | 1366×768 |
| LP140WX1-TL02 | LG Display | 14.0 | 1280×768 |
| B154EW04 V7 | AUO | 15.4 | 1280×800 |
| B156XW02 V0 | AUO | 15.6 | 1366×768 |
| HB140WX1-301 | BOE | 14.0 | 1366×768 |
| HT121X01-101 | HYDIS | 12.1 | 1024×768 |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LP154WP3-TLA3 | LG Display | 15.4 | 1440×900 |
| LTM10C349 | TOSHIBA | 10.4 | 800×600 |
| LTN121AT02-A01 | Samsung | 12.1 | 1280×800 |
| LTN133AT23-803 | Samsung | 13.3 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
