| Varenummer | LP154WE3-TLB1 |
| Mærke | LG Display |
| Størrelse | 15.4 |
| Ansøgning | NBPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP154WE3-TLB1 3 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.4 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 331.38×207.11 mm |
| omrids | 342.85×229.87×4.03 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | Antiglare |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP154W01-TLA3 | LG Display | 15.4 | 1280×800 |
| LP154WE2-TLA8 | LG Display | 15.4 | 1680×1050 |
| LP154WE3-TLA1 | LG Display | 15.4 | 1680×1050 |
| LP154WP2-TLC2 | LG Display | 15.4 | 1440×900 |
| LP154WP4-TLB1 | LG Display | 15.4 | 1440×900 |
| LP154WU1-A1K3 | LG Display | 15.4 | 1920×1200 |
| LP154WX4-TLC5 | LG Display | 15.4 | 1280×800 |
| LP154WX4-TLC8 | LG Display | 15.4 | 1280×800 |
| LP154WX4-TLCB | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLA1 | LG Display | 15.4 | 1280×800 |
| B133XTN02.1 | AUO | 13.3 | 1366×768 |
| B141EW03 V3 | AUO | 14.1 | 1280×800 |
| B154SW01 V9 | AUO | 15.4 | 1680×1050 |
| LP121X04-C2 | LG Display | 12.1 | 1024×768 |
| LP140WH2-TLM2 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLA1 | LG Display | 14.0 | 1366×768 |
| LP141WX3-TLQ1 | LG Display | 14.1 | 1280×800 |
| LTN140AT20-301 | Samsung | 14.0 | 1366×768 |
| LTN141W1-L04 | Samsung | 14.1 | 1280×800 |
| N164HGE-L12 | Innolux | 16.4 | 1920×1080 |
