| Varenummer | LP156WF3-SLB3 |
| Mærke | LG Display |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 210 |
| CR | 800:1 |
| Farver | 1.07B |
| Baggrundsbelysning | RGB LED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP156WF3-SLB3 2 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 344.16×193.59 mm |
| omrids | 359.3×212.1×7.2 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 210 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 1.07B (10-bit) |
| responstid | 30 (Typ.)(Tr+Td); 15 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | RGB LEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 10-bit), 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
