| Varenummer | LP171WP4-TLR1 |
| Mærke | LG Display |
| Størrelse | 17.1 |
| Ansøgning | NBPC |
| Løsning | 1440×900 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LP171WP4-TLR1 9 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.1 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| omrids | 382.2×244.5×6.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (2H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP171WP4-TLB1 | LG Display | 17.1 | 1440×900 |
| LP171WPA-TLA1 | LG Display | 17.1 | 1440×900 |
| LP171WU1-A4K3 | LG Display | 17.1 | 1920×1200 |
| LP171WU1-TLA2 | LG Display | 17.1 | 1920×1200 |
| LP171WU3-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WU5-TLA2 | LG Display | 17.1 | 1920×1200 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LP171WU6-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WX2-A4K1 | LG Display | 17.1 | 1440×900 |
| LP171WX2-TLB2 | LG Display | 17.1 | 1440×900 |
| B154EW02 V6 | AUO | 15.4 | 1280×800 |
| B156XTN02.4 | AUO | 15.6 | 1366×768 |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V1 | AUO | 17.0 | 1440×900 |
| HB140WX1-301 | BOE | 14.0 | 1366×768 |
| LP141WP1-TLA3 | LG Display | 14.1 | 1440×900 |
| LP156WD1-TPB1 | LG Display | 15.6 | 1600×900 |
| LTN121AT11-801 | Samsung | 12.1 | 1280×800 |
| N140BGE-L33 | Innolux | 14.0 | 1366×768 |
| N156BGE-E42 | Innolux | 15.6 | 1366×768 |
