| Varenummer | LP171WP6-TL04 |
| Mærke | LG Display |
| Størrelse | 17.1 |
| Ansøgning | NBPC |
| Løsning | 1440×900 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 700:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LP171WP6-TL04 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.1 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| omrids | 382.2×246.8×10 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (2H), Antireflection |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP171WP6-TL04 | LG Display | 17.1 | 1440×900 |
| LP171WP9-TLB2 | LG Display | 17.1 | 1440×900 |
| LP171WU1-A4K2 | LG Display | 17.1 | 1920×1200 |
| LP171WU1-TLA3 | LG Display | 17.1 | 1920×1200 |
| LP171WU3-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WU5-TLA2 | LG Display | 17.1 | 1920×1200 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LP171WU6-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WU8-SLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WX2-TLB1 | LG Display | 17.1 | 1440×900 |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B154SW02 V0 | AUO | 15.4 | 1680×1050 |
| HSD173PUW1-A01 | HannStar | 17.3 | 1920×1080 |
| LP154WX4-TLA1 | LG Display | 15.4 | 1280×800 |
| LP156WH2-TPB1 | LG Display | 15.6 | 1366×768 |
| LP173WF1-TLB2 | LG Display | 17.3 | 1920×1080 |
| LTM10C348P | TOSHIBA | 10.4 | 800×600 |
| LTN156AT23-W01 | Samsung | 15.6 | 1366×768 |
| LTN160AT01-A02 | Samsung | 16.0 | 1366×768 |
| LTN170BT05-G01 | Samsung | 17.0 | 1440×900 |
