| Varenummer | LQ104V1DG52 |
| Mærke | SHARP |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ104V1DG52 4 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 211.2×158.4 mm |
| omrids | 246.5×179.4×15.5 mm |
| overflade | Antiglare, Hard coating (3H), Antireflection |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/25 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/40/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| indgangsspænding | 3.3/5.0V (Typ.) |
| Ansøgning | IA |
| LQ104S1DG61 | SHARP | 10.4 | 800×600 |
| LQ104V1DC31 | SHARP | 10.4 | 640×480 |
| LQ104V1DG11 | SHARP | 10.4 | 640×480 |
| LQ104V1DG33 | SHARP | 10.4 | 640×480 |
| LQ104V1DG52 | SHARP | 10.4 | 640×480 |
| LQ104V1DG59 | SHARP | 10.4 | 640×480 |
| LQ104V1DG5A | SHARP | 10.4 | 640×480 |
| LQ104V1DG72 | SHARP | 10.4 | 640×480 |
| LQ104V1DW01 | SHARP | 10.4 | 640×480 |
| LQ104X2LX05A | SHARP | 10.4 | 1024×768 |
| AA121TD01 | Mitsubishi | 12.1 | 1280×800 |
| G057VGE-T01 | Innolux | 5.7 | 640×480 |
| G084SN03 V2 | AUO | 8.4 | 800×600 |
| G190EG02 V0 | AUO | 19.0 | 1280×1024 |
| LTM10C209AF | TOSHIBA | 10.4 | 640×480 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| PD064VT4 | E Ink | 6.4 | 640×480 |
| PD104SLD | E Ink | 10.4 | 800×600 |
| SP24V001 | KOE | 9.4 | 640×480 |
