| Varenummer | G190EG02 V0 |
| Mærke | AUO |
| Størrelse | 19.0 |
| Ansøgning | IA |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 2000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | G190EG02 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 376.32×301.056 mm |
| omrids | 396×324×21.85 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 2000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
