| Varenummer | LQ104V1LG92 |
| Mærke | SHARP |
| Størrelse | 10.4 |
| Ansøgning | GM |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 330 |
| CR | |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ104V1LG92 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 211.2×158.4 mm |
| omrids | 240×179.2 mm |
| overflade | |
| lysstyrke | 330 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFL |
| signal interface | LVDS (1 ch, 8-bit) |
| Ansøgning | GM |
