| Varenummer | LQ121S1LG45 |
| Mærke | SHARP |
| Størrelse | 12.1 |
| Ansøgning | GM |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 370 |
| CR | 450:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ121S1LG45 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 276×209×11 mm |
| overflade | Antiglare, Hard coating (3H), Antireflection |
| lysstyrke | 370 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 15/30 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VCC) |
| Ansøgning | GM |
| LQ121K1LG52 | SHARP | 12.1 | 1280×800 |
| LQ121S1DG31 | SHARP | 12.1 | 800×600 |
| LQ121S1DG43 | SHARP | 12.1 | 800×600 |
| LQ121S1LG44 | SHARP | 12.1 | 800×600 |
| LQ121S1LG45 | SHARP | 12.1 | 800×600 |
| LQ121S1LG79 | SHARP | 12.1 | 800×600 |
| LQ121S1LH03 | SHARP | 12.1 | 800×600 |
| LQ121X1LH22 | SHARP | 12.1 | 1024×768 |
| LQ121X1LH73 | SHARP | 12.1 | 1024×768 |
| LQ121X3LH01 | SHARP | 12.1 | 1024×768 |
| A121EW02 V0 | AUO | 12.1 | 1280×800 |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| G154I1-LE1 | Innolux | 15.4 | 1280×800 |
| L5S30341P00 | SANYO | 12.1 | 800×600 |
| LM215WF3-SLK1 | LG Display | 21.5 | 1920×1080 |
| LM265SQ1-SLA1 | LG Display | 26.5 | 1920×1920 |
| LQ156M1LG21 | SHARP | 15.6 | 1920×1080 |
| LQ190E1LX75 | SHARP | 19.0 | 1280×1024 |
| P64CN1 | E Ink | 6.4 | 320×234 |
| TFD70W11-F1 | TOSHIBA | 7.0 | 480×234 |
