| Varenummer | LQ125T1JW02 |
| Mærke | SHARP |
| Størrelse | 12.5 |
| Ansøgning | NBPC |
| Løsning | 2560×1440 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | SHARP |
| panel model | LQ125T1JW02 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 12.5 inch |
| løsning | 2560(RGB)×1440 , Quad-HD |
| visningstilstand | Normally Black, Transmissive |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | eDP (4 Lanes) |
| rohs: | |
| Ansøgning | NBPC |
