| Varenummer | LT057AC47000 |
| Mærke | Toshiba Mobile Displ |
| Størrelse | 5.7 |
| Ansøgning | Industrial |
| Løsning | 640×480 |
| Sammensætning | LTPS TFT-LCD, LCM |
| Lysstyrke | |
| CR | 500:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | Toshiba Mobile Display |
| model | LT057AC47000 |
| diagonal størrelse | 5.7 inch |
| type | LTPS TFT-LCD, LCM |
| pixel format | 640(RGB)×480 [VGA] 141PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 115.2(H)×86.4(V) mm |
| omrids dim. | - |
| luminans | - |
| kontrastforhold | 500:1 (Typ.) (TM) |
| visningsretning | 12 o'clock |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/55/45 (Typ.)(CR≥10) |
| driftstilstand | TN, Normally White, Transmissive |
| støtte farve | 262K/16.2M |
| lyskilde | WLED , 70K hours |
| vægt | - |
| designet til | Industrial |
| billedhastighed | - |
| berøringspanel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
