| Varenummer | LM057QB1T073 |
| Mærke | SHARP |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 150 |
| CR | 6:1 |
| Farver | Monochrome |
| Baggrundsbelysning | WLED |
| Interface | Parallel Data |
| panel mærke | SHARP |
| panel model | LM057QB1T073 |
| paneltype | STN-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 320×240 , QVGA |
| visningstilstand | STN, Blue mode (Negative), Transmissive |
| aktivt område | 115.17×86.37 mm |
| omrids | 166×109×7.5 mm |
| overflade | |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 6:1 (Typ.) |
| vise farver | Monochrome |
| responstid | 190/210 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/25/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekvens | 80Hz |
| lampe type | 1S6PWLEDEmbedded (LED Driver) |
| signal interface | Parallel Data (4-bit), 12 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
