| Varenummer | LTA075A362F |
| Mærke | TOSHIBA |
| Størrelse | 7.5 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 450:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | Toshiba Matsushita |
| panel model | LTA075A362F |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.5 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 151.68×113.76 mm |
| omrids | 195.2×137.5 mm |
| overflade | |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 32 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | IA |
| KCG075VG2BB-G00 | Kyocera | 7.5 | 640×480 |
| LQ075V3DG01 | SHARP | 7.5 | 640×480 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| LTA070B070F | TOSHIBA | 7.0 | 800×480 |
| LTA070B0C0A | TOSHIBA | 7.0 | 480×234 |
| LTA070B240F | TOSHIBA | 7.0 | 480×234 |
| LTA070B2C0F | TOSHIBA | 7.0 | |
| LTA070B511F | TOSHIBA | 7.0 | 800×480 |
| LTA070B792F | TOSHIBA | 7.0 | 800×480 |
| LTA075A362F | TOSHIBA | 7.5 | 640×480 |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| LM64C15P | SHARP | 9.4 | 640×480 |
| LQ9D001 | SHARP | 8.4 | 640×480 |
| NL8060BC21-11 | NLT | 8.4 | 800×600 |
| PD104SLG | E Ink | 10.4 | 800×600 |
| SX19V001-ZZB | KOE | 7.5 | 640×480 |
| TX20D16VM2BAA | KOE | 8.0 | 800×480 |
| TX26D02VM1CAA | KOE | 10.4 | 640×480 |
| UG-2864ASWPG01 | WiseChip | 2.4 | 128×64 |
