| Varenummer | LTA080B441A |
| Mærke | TOSHIBA |
| Størrelse | 8.0 |
| Ansøgning | |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 300:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | Toshiba Matsushita |
| panel model | LTA080B441A |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 175.68×99.45 mm |
| omrids | 187×113 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | Full color |
| responstid | 11/22 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/30/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| indgangsspænding | 3.3/5.0/17/-13V (Typ.)(VDD/VEE/VGON/VSS) |
| rohs: |
