| Varenummer | LTA520HB04 |
| Mærke | Samsung |
| Størrelse | 52 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 3000:1 |
| Farver | 1.06B |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTA520HB04 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 52 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-PVA, Normally Black, Transmissive |
| aktivt område | 1152×648 mm |
| omrids | 1226×719.2 mm |
| overflade | Antiglare (Haze 14%), Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 1.06B (8-bit + FRC), CIE193172% |
| responstid | 14/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 24 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 10-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
